G4 / U6 Sensus LPG Natural Gas Meter with 45 Degree Angled Index suitable for Household and Static Caravan

• U6 G4 Gas Meter
• Compatible with LPG, natural gas, and town gas
• Suitable for static caravan and residential use
• Suitable for recessed and surface mounted installations
• Fireproof to EN1359 standard
• Transco and OFGEM Approved
• 152mm hole centres
• 1″ BS746 male connections
• 45 degree angled index

Sensus G4 / U6 LPG Natural Town Gas Meter Specification

• Cyclic volume: 2.0 dm3
• Rated capacity Q max: 6.0 m3/hr
• Rated capacity Q min: 0.04 m3/hr
• Working pressures up to: 0.5 bar
• Weight: 4 kg
• Max. index reading: 99999,999 m3
• Case work: Corrosion resistant coated steel
• Finish: Powder Coated
• Fire resistant to: BS4161 (821°C rise in 30 min)
• Gas: Natural, manufactured or LPG
• Diaphragms: Synthetic
• Typical connection size: 1″ threaded
• Outputs: Integral / retrofit
• Pulse value: 0.01m3
• Max ratings : 12Vdc 10mA

G4 / U6 LPG and Natural Gas Meter Installation

All gas appliances must be installed by a qualified Gas Safe registered engineer.
